Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier

China Anping County PeiGuan Metal Wire Mesh Products Co.,Ltd certification
Fantastic company. So helpful and friendly. Nothing is too much trouble even though I had many questions. Received the fence much faster than I expected. Very good quality. My customers are very pleased with the fence. This easily the best company from China I have done business. I can't recommend them enough.

—— Maja Bjornsdotter

Fast, compenent, good wire mesh fence product quality and great service. We will definitely be a returning customer.

—— Harald Schreiner

I'm Online Chat Now

Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier

Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier
Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier

Large Image :  Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier

Product Details:
Place of Origin: PeiGuan Metal Wire Mesh; Anping; China
Brand Name: PeiGuan
Certification: SGS
Model Number: HBB-H01
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: pallet or in bulk
Delivery Time: According to the order
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 5000 Set/Sets per Month
Detailed Product Description
Product Name: Bastion Barrier Mateial: Hot Dipped Galvanized
Wire Diameter: 4mm-5mm Mesh Size: 75mm X 75mm Or 3" X 3"
Dimension: MIL1-MIL12 Cells: 5+5=10cells
Geotextile Fabric: 300g/m^2 Color: Grey, Beige, Or Military Green
Hole Shape: Square Processing Service: Welding
Geotextile Gramweight:: 300g/m² Surface Treatment: Hot-dipped Galvanized, Galfan Coated
High Light:

1.0x1.0x10m hesco bastion barrier

,

mil 3 galvanized hesco bastion barrier

,

mil 3 galvanized hesco fence

MIL-3 Hot-Dipped Galvanized 1.0*1.0*10m Hesco Bastion Barrier



Product Description



Military defensive hesco barriers mil 10 is one modern welded gabion basket which can be filled with sand, earth, gravel, aggregates, rubble, bricks, even some fine sediment, etc.

Hesco defensive barriers are widely used for explosion-proof against attacks from rifle bullets, shell fragments, rocket propelled grenade round, so its another name is hesco flood control barrier.

In both military sand security applications the military barrier affords protection from small arms fire right up to VBIEDs and artillery. PeiGuan's military defensive barriers are mainly used for Homeland Security applications providing critical infrastructure protection including perimeter security, vehicle barriers and inspection lanes as well as temporary or permanent barriers.



Product Details



Product Item NO. Height Width Length Cells NO.
PG MIL1 54"(1.37M) 42''(1.06M) 32'9''(10M) 5+4=9 cells
PG MIL2 24''(0.61M) 24''(0.61M) 4'(1.22M) 2 cells
PG MIL3 39''(1.00M) 39''(1.00M) 32'.9''(10M) 5+5=10 cells
PG MIL4 39''(1.00M) 60''(1.52M) 32'.9''(10M) 5×2+5×2=20 cells
PG MIL5 24''(0.61M) 24''(0.61M) 10'(3.05M) 5 cells
PG MIL6 66''(1.68M) 24''(0.61M) 10'(3.05M) 5 cells
PG MIL7 87''(2.21M) 84''(2.13M) 91'(27.74M) 5+4+4=13 cells
PG MIL8 54''(1.37M) 48''(1.22M) 32'.9''(10M) 5+4=9 cells
PG MIL9 39''(1.00M) 30''(0.76M) 30'(9.14M) 6+6=12 cells
PG MIL10 87''(2.21M) 60''(1.52M) 100'(30.50M) 5+5+5+5=20 cells
PG MIL11 48''(1.22M) 12''(0.30M) 4'(1.22M) 2 cells
PG MIL12 84"(2.13M) 42"(1.06M) 108"(33M) 5+5+5+5+5+5=30 cells
PG MIL19 108''(2.74M) 42"(1.06M) 10'5'(3.18M) 6 cells

Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier 0

Applications:



  • Personnel bunkers
  • Guard post
  • Police force points and Check points
  • Military Defensive barriers
  • Perimeter security barrier or border barrier
  • Temporary fort and command post
  • Observation points and border checkpoints
  • Shell proof defence barrier
  • Alert or cautionary outpost
  • Flood prevention barrier
  • Military barrier fortification system
  • Permanent or Semi-permanent Dike



Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier 1



Packing



Usually wrapped with shrink film and packed in pallet.

Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier 2

Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier 3Mil 3 Hot Dipped Galvanized 1.0x1.0x10m Hesco Bastion Barrier 4
