Anping County PeiGuan Metal Wire Mesh Products Co.,Ltd
Home ProductsV Mesh Security Fencing

3m V Mesh Security Fencing , 3D Welded V Mesh Panels

China Anping County PeiGuan Metal Wire Mesh Products Co.,Ltd certification
Fantastic company. So helpful and friendly. Nothing is too much trouble even though I had many questions. Received the fence much faster than I expected. Very good quality. My customers are very pleased with the fence. This easily the best company from China I have done business. I can't recommend them enough.

—— Maja Bjornsdotter

Fast, compenent, good wire mesh fence product quality and great service. We will definitely be a returning customer.

—— Harald Schreiner

I'm Online Chat Now

3m V Mesh Security Fencing , 3D Welded V Mesh Panels

3m V Mesh Security Fencing  , 3D Welded V Mesh Panels
3m V Mesh Security Fencing  , 3D Welded V Mesh Panels 3m V Mesh Security Fencing  , 3D Welded V Mesh Panels 3m V Mesh Security Fencing  , 3D Welded V Mesh Panels 3m V Mesh Security Fencing  , 3D Welded V Mesh Panels

Large Image :  3m V Mesh Security Fencing , 3D Welded V Mesh Panels

Product Details:

Place of Origin: Pei Guan Metal Wire Mesh; Anping; China
Brand Name: PeiGuan
Certification: SGS
Model Number: VMF-J07

Payment & Shipping Terms:

Minimum Order Quantity: 100 pieces
Price: Negotiable
Packaging Details: Usually wrapped with shrink film and packed in pallet.
Delivery Time: 25 day
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 10000 Piece/Pieces per Month
Detailed Product Description
Product Name: V Mesh Security Fencing Materials: Galvanized Steel Wire
Wire Diameter: 3.0mm-6.0mm Mesh: 50mm * 200mm
Hole Shape: Square Height: 1030mm/1230mm/1530mm/1830mm
Length: 2000mm/2200mm/2500mm/3000mm Folded No: 2/3/4
Surface Treatment: Hot Dipped Galvanized/ Powder Coated Feature: Easily Assembled, Eco Friendly,
High Light:

3m V Mesh Security Fencing

,

Farm V Mesh Security Fencing

,

1030mm V Mesh Panels

3.0m Height V Wire Mesh Fencing / Triangle Bending Fence for Farm



Description:



3D Welded V Mesh Fence is made from strong welded steel wire, rectangular mesh and horizontal reinforcement, maintaining high strength, quality and performance, providing safety and security without an oppressive and intimidating appearance. Corrosion resistant galvanised and PVC coated for long life, low maintenance and an attractive appearance. In addition, they can be colour coated and are available in a wide range of colours. It is suitable for a wide range of applications, such as for enclosing commercial sites, lawns and roads.



Panel Specification:



Mesh Size

Wire

Diameter

Panel

Height

Panel

Length

Bending No.

Common Color

Surface Treatment

50*200mm

50*100mm

55*200mm

55*100mm

4mm

5mm

830mm

2m

2.2m

2.4m

2.5m

2.8m

3m

2

Green RAL 6005

Grey RAL 7016

Brown RAL 8019

Black RAL 9005

White RAL 9010

1.Hot dipped galvanized after black wire welded



2.PVC coated after galvanized wire welded



3.PE coated after galvanized wire welded



4.Powder coated after galvanized wire welded

1030mm

2

1230mm

2

1530mm

3

1830mm

4

2030mm

4

2230mm

4

2430mm

4



Square Post & Rectangular Post:



Post Type Post Size

Post Thickness

Panel Height Post Height Surface Treatment
Square Post

40*40mm

50*50mm

60*60mm

1.0mm

1.1mm

1.2mm

1.5mm

1.8mm

2.0mm

2.5mm

830mm 1200mm

hot-dipped galvanized



PVC coated



powder coated

1030mm 1400mm
1230mm 1600mm
1530mm 2000mm
Rectangle Post

30*50mm

40*60mm

60*80mm

1830mm 2400mm
2030mm 2600mm
2230mm 2800mm
2430mm 3000mm



Peach Post:



Post Type

Post Size

Thickness

Panel Height

Post Height

Surface Treatment

Peach Post

50*70mm

1.0mm

1.1mm

1.2mm

830mm

1200mm

Galvanized tube powder coated

1030mm

1400mm

1230mm

1600mm

1530mm

2000mm

70*100mm

1830mm

2400mm

2030mm

2600mm

2230mm

2800mm

2430mm

3000mm



3m V Mesh Security Fencing  , 3D Welded V Mesh Panels 0



Feature:



1. Very high stiffness
    4 mm, 5 mm mild steel wire ensures the most toughness and resistance to compression of 3D bending panels

2. Security guarantee
    As a fence for applications with high security requirements, as the small holes and heavy metal wire provide a high degree of security.

3. Durability
    The galvanised heavy wire panels are sealed with an epoxy resin coating prior to the PVC coating to ensure a longer service life.

4. Long service life
    The latest coating technology guarantees an extremely long service life. After galvanising, a special coating is applied to ensure perfect adhesion of the PVC coating.

5. Fencing system integrity
    The system consists of panels with different mesh holes and heights, posts with a suitable retainer system and a large number of gates. All components guarantee a quick and precise installation.

6. Aesthetics and architecture
     The design of the fence is attractive for upmarket and high-tech architectural applications. Its versatility and unique features make it an exceptional system that never compromises on safety and quality.



Application:

  • High Security Projects
  • Transportation Projects
  • sports facilities
  • Bordering
  • Industry Facilities
  • Housing Projects

Packing terms:

  • Fence panels. Bulk, plastic film packed on wooden/metal pallets
  • Fence posts. Plastic film packed on wooden tow trays/metal pallets
  • Accessories. In woven bags or cardboard boxes

3m V Mesh Security Fencing  , 3D Welded V Mesh Panels 13m V Mesh Security Fencing  , 3D Welded V Mesh Panels 23m V Mesh Security Fencing  , 3D Welded V Mesh Panels 3

3m V Mesh Security Fencing  , 3D Welded V Mesh Panels 4
