Military Defensive MIL8 Hesco Blast Walls For Shooting

Military Defensive MIL8 Hesco Blast Walls For Shooting
Military Defensive MIL8 Hesco Blast Walls For Shooting Military Defensive MIL8 Hesco Blast Walls For Shooting Military Defensive MIL8 Hesco Blast Walls For Shooting Military Defensive MIL8 Hesco Blast Walls For Shooting

Large Image :  Military Defensive MIL8 Hesco Blast Walls For Shooting

Product Details:
Place of Origin: PeiGuan Metal Wire Mesh;Anping;China
Brand Name: PeiGuan
Certification: SGS
Model Number: HB-S01
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Usually wrapped with shrink film and packed in pallet.
Delivery Time: According to the order
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability: 10000 Sets per Month
Detailed Product Description
Product Name: Hesco Bastion Barrier Aperture: 75*75mm Or 3''*3''
Surface Treatment:: Hot-dipped Galvanized, Galfan Coated Material: Galvanized Iron Wire
Wire Diameter: 4mm, 5mm Type: Welded Mesh
Dimension: MIL1-MIL12 Geotextile: 300g/m2
Color: Beige, Military Green Hole Shape: Square
High Light:

MIL8 Hesco Blast Walls

,

4mm Military Defensive Hesco Blast Walls

,

4mm Military Sand Barrier

Military Defensive MIL8 Hesco Barrier Bastion Blast Wall For Shooting





Product Description



Hesco Bostion Barrier also known as a fort is a modern metal mesh or flood control wall , and the traditional stone cage net (stone basket) is different, not only can be loaded with stone, and even can be loaded with finer sediment, filling materials locally sourced, especially suitable for the lack of stone in the downstream rivers or coastal use. With the help of excavators, forklifts and other advanced tools, the installation efficiency is dozens of times or even hundreds of times that of traditional sandbags.used for flood control and military fortifications.



Composed of a collapsible mesh container and heavy geotextiles, it is used as a temporary fortress to block or small attacks.is made of external welded gabion mesh and interior fabric liner. It is originally used to control flood and erosion of beaches and marshes. Recently, it has been frequently applied to military purposes. Quick installation and rigid structure ensures temporary or semi-permanent dike or barrier against explosions or small arms.



Specifications



PRODUCT ITERM NO. HEIGHT WIDTH LENGTH CELLS NO.
PG MIL1 54''(1.37M) 42''(1.06M) 32'9''(10M) 5+4=9 cells
PG MIL2 24'' (0.61M) 24''(0.61M) 4'(1.22M) 2 cells
PG MIL3 39''(1.00M) 39''(1.00M) 32'.9''(10M) 5+5=10 cells
PG MIL4 39''(1.00M) 60''(1.52M) 32'.9''(10M) 5×2+5×2=20 cells
PG MIL5 24''(0.61M) 24''(0.61M) 10'(3.05M) 5 cells
PG MIL6 66''(1.68M) 24''(0.61M) 10'(3.05M) 5 cells
PG MIL7 87''(2.21M) 84''(2.13M) 91'(27.74M) 5+4+4=13 cells
PG MIL8 54''(1.37M) 48''(1.22M) 32'.9''(10M) 5+4=9 cells
PG MIL9 39''(1.00M) 30''(0.76M) 30'(9.14M) 6+6=12 cells
PGMIL10 87''(2.21M) 60''(1.52M) 100'(30.50M) 5+5+5+5=20 cells
PG MIL11 48''(1.22M) 12''(0.30M) 4'(1.22M) 2 cells
PG MIL12 84"(2.13M) 42"(1.06M) 108"(33M) 5+5+5+5+5+5=30 cells
PG MIL19 108''(2.74M) 42"(1.06M) 10'5'(3.18M) 6 cells



Features



1. Easy to handle and install, outstanding effect

2. High strength and impact resistance

3. Long life

4. Normal use can be filled with sand, cement, stone, soil

5. It can be used together to any length, and can be stacked for additional height

6. Easy to transport folding packaging, mobility is very strong

7. Conducive to recovery



Applications



1. Hesco Shooting Range

2. Military Defensive & Flood Control

3. Personnel and material bunkers

4. Observation points & Road checkpoints

5. Border checkpoints, protecting existing structures

6. Highway traffic management

7. River emergency flood control deployment erosion control retaining wall



Installation



1. Unpack the collapsible wire mesh container from package.

2. Unfold the barrier and connect barriers to reach the designed length

3. Fill soil, sand or gravel into the container.

4. Compact the content

5. Add layers if required.



Our Service



1. Provide most of free samples

2. Spot inspection and finished product inspection

3. 24 hours to answer your questions and doubts



Military Defensive MIL8 Hesco Blast Walls For Shooting 0Military Defensive MIL8 Hesco Blast Walls For Shooting 1Military Defensive MIL8 Hesco Blast Walls For Shooting 2
