Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier

China Anping County PeiGuan Metal Wire Mesh Products Co.,Ltd certification
Fantastic company. So helpful and friendly. Nothing is too much trouble even though I had many questions. Received the fence much faster than I expected. Very good quality. My customers are very pleased with the fence. This easily the best company from China I have done business. I can't recommend them enough.

—— Maja Bjornsdotter

Fast, compenent, good wire mesh fence product quality and great service. We will definitely be a returning customer.

—— Harald Schreiner

I'm Online Chat Now

Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier

Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier
Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier

Large Image :  Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier

Product Details:
Place of Origin: PeiGuan Metal Wire Mesh; Anping; China
Brand Name: PeiGuan
Certification: SGS
Model Number: HBB-J07
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: pallet or in bulk
Delivery Time: According to the order
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10000 Set/Sets per Month
Detailed Product Description
Name: Hesco Bastion Barrier Wire Gauge: 4mm; 5mm
Mesh: 75*75mm Or 3''*3'' Hole Shape: Square
Processing Service: Welding Dimension: MIL1-MIL12
Cells: 5+4=9 Surface Treatment: Hot-dipped Galvanized, Galfan Coated
Application: Hesco Shooting Range Geotextile: 300g/m2
High Light:

4mm Hesco Defensive Barriers

,

Galvanized Hesco Defensive Barriers

,

Military Sand Wall Hesco Barrier

4 Mm High quality Anti Explosion Galvanized Hesco Barrier For Kenya



Description:



Hesco defensive barriers are widely used for explosion-proof against attacks from rifle bullets, shell fragments, rocket propelled grenade round, especially used in Afghanistan, Iraq, Jordan, etc. It is also used for flood control in cities, so its another name is Hesco flood control barrier. And it is also known as Rock basket retaining wall, hesco barrier, flood control barrier, etc. which is made of the steel welded mesh and lined with non-woven textile, can be filled with sand, earth, cement, stone, then as a defensive wall or bunker and widely used in the military to protect safety.



Brief description:



1. A pre-fabricated gabion of galvanized welded mesh steel fitted with a UV-protecting.

2. Polypropylene geo-textile liner.

3. Filling material is an easy- obtained mix of sand and small stones.

4. It can be used together to any length, and can be stacked for additional height.



Specification:

  • Diameter:4mm; 5mm

  • Color Silver, green, Gray, Blue, Yellow

  • Material Galvanized steel wire

  • Size :height 1.37m x width 1.06m x length 10m

  • Mesh opening: 75*75mm or 3''*3''

  • Packing terms:Usually wrapped with shrink film and packed in pallet.

 ITERM NO. HEIGHT WIDTH LENGTH CELLS NO.
PG MIL1 54''(1.37M) 42''(1.06M) 32'9''(10M) 5+4=9 cells
PG MIL2 24'' (0.61M) 24''(0.61M) 4'(1.22M) 2 cells
PG MIL3 39''(1.00M) 39''(1.00M) 32'.9''(10M) 5+5=10 cells
PG MIL4 39''(1.00M) 60''(1.52M) 32'.9''(10M) 5×2+5×2=20 cells
PG MIL5 24''(0.61M) 24''(0.61M) 10'(3.05M) 5 cells
PG MIL6 66''(1.68M) 24''(0.61M) 10'(3.05M) 5 cells
PG MIL7 87''(2.21M) 84''(2.13M) 91'(27.74M) 5+4+4=13 cells
PG MIL8 54''(1.37M) 48''(1.22M) 32'.9''(10M) 5+4=9 cells
PG MIL9 39''(1.00M) 30''(0.76M) 30'(9.14M) 6+6=12 cells
PGMIL10 87''(2.21M) 60''(1.52M) 100'(30.50M) 5+5+5+5=20 cells
PG MIL11 48''(1.22M) 12''(0.30M) 4'(1.22M) 2 cells
PG MIL12 84"(2.13M) 42"(1.06M) 108"(33M) 5+5+5+5+5+5=30 cells
PG MIL19 108''(2.74M) 42"(1.06M) 10'5'(3.18M) 6 cells



Application:



  • Military Defensive Walls

  • Accommodation Bunkers

  • Army Training Grounds & Shoot Houses

  • Ammunition Storage

  • Explosive Traverses

  • Hostile Vehicle Mitigation

  • Forwarder Operating Bases

  • Perimeter Security

  • Blast & Ballistic Protection

  • Command & Control Centers



Packing Show:

Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier 0Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier 1

Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier 2Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier 3

Anti Explosion Hesco Defensive Barriers , 4mm Military Sand Wall Hesco Barrier 4
