Product Details:
Payment & Shipping Terms:
|
| Name: | Bastion Barrier | Wire Gauge: | 4mm; 5mm |
|---|---|---|---|
| Mesh: | 75*75mm Or 3''*3'' | Hole Shape: | Square |
| Processing Service: | Welding | Dimension: | MIL1-MIL12 |
| Cells: | 5+4=9 | Surface Treatment: | Hot-dipped Galvanized, Galfan Coated |
| Application: | Shooting Range | Geotextile: | 300g/m2 |
| Highlight: | 4mm Defensive Barriers,Galvanized Defensive Barriers,Military Sand Wall Barrier |
||
4 Mm High quality Anti Explosion Galvanized Barrier For Kenya
Description:
defensive barriers are widely used for explosion-proof against attacks from rifle bullets, shell fragments, rocket propelled grenade round, especially used in Afghanistan, Iraq, Jordan, etc. It is also used for flood control in cities, so its another name is flood control barrier. And it is also known as Rock basket retaining wall, barrier, flood control barrier, etc. which is made of the steel welded mesh and lined with non-woven textile, can be filled with sand, earth, cement, stone, then as a defensive wall or bunker and widely used in the military to protect safety.
Brief description:
1. A pre-fabricated gabion of galvanized welded mesh steel fitted with a UV-protecting.
2. Polypropylene geo-textile liner.
3. Filling material is an easy- obtained mix of sand and small stones.
4. It can be used together to any length, and can be stacked for additional height.
Specification:
Diameter:4mm; 5mm
Color Silver, green, Gray, Blue, Yellow
Material Galvanized steel wire
Size :height 1.37m x width 1.06m x length 10m
Mesh opening: 75*75mm or 3''*3''
Packing terms:Usually wrapped with shrink film and packed in pallet.
| ITERM NO. | HEIGHT | WIDTH | LENGTH | CELLS NO. |
| PG MIL1 | 54''(1.37M) | 42''(1.06M) | 32'9''(10M) | 5+4=9 cells |
| PG MIL2 | 24'' (0.61M) | 24''(0.61M) | 4'(1.22M) | 2 cells |
| PG MIL3 | 39''(1.00M) | 39''(1.00M) | 32'.9''(10M) | 5+5=10 cells |
| PG MIL4 | 39''(1.00M) | 60''(1.52M) | 32'.9''(10M) | 5×2+5×2=20 cells |
| PG MIL5 | 24''(0.61M) | 24''(0.61M) | 10'(3.05M) | 5 cells |
| PG MIL6 | 66''(1.68M) | 24''(0.61M) | 10'(3.05M) | 5 cells |
| PG MIL7 | 87''(2.21M) | 84''(2.13M) | 91'(27.74M) | 5+4+4=13 cells |
| PG MIL8 | 54''(1.37M) | 48''(1.22M) | 32'.9''(10M) | 5+4=9 cells |
| PG MIL9 | 39''(1.00M) | 30''(0.76M) | 30'(9.14M) | 6+6=12 cells |
| PGMIL10 | 87''(2.21M) | 60''(1.52M) | 100'(30.50M) | 5+5+5+5=20 cells |
| PG MIL11 | 48''(1.22M) | 12''(0.30M) | 4'(1.22M) | 2 cells |
| PG MIL12 | 84"(2.13M) | 42"(1.06M) | 108"(33M) | 5+5+5+5+5+5=30 cells |
| PG MIL19 | 108''(2.74M) | 42"(1.06M) | 10'5'(3.18M) | 6 cells |
Application:
Military Defensive Walls
Accommodation Bunkers
Army Training Grounds & Shoot Houses
Ammunition Storage
Explosive Traverses
Hostile Vehicle Mitigation
Forwarder Operating Bases
Perimeter Security
Blast & Ballistic Protection
Command & Control Centers
Packing Show:
