4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets

Fantastic company. So helpful and friendly. Nothing is too much trouble even though I had many questions. Received the fence much faster than I expected. Very good quality. My customers are very pleased with the fence. This easily the best company from China I have done business. I can't recommend them enough.

—— Maja Bjornsdotter

Fast, compenent, good wire mesh fence product quality and great service. We will definitely be a returning customer.

—— Harald Schreiner

I'm Online Chat Now

4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets

4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets
4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets 4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets 4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets

Large Image :  4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets

Product Details:
Place of Origin: China
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: 100 Sets
Price: Negotiable
Packaging Details: pallet or in bulk
Delivery Time: According to the order
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10000 Square Meter/Square Meters per Day
Detailed Product Description
Name: Welded Mesh Gabion Gabion Box Size: 100*30*30 Cm, 100*100*50 Cm
Hole Shape: Square, Rectangle Wire Gauge: 4mm 5mm 6mm
Surface Treatment: Hot Dip Galvanized Material: Low Carbon Iron Wire
Certification: SGS Packing: Waterproof Paper
High Light:

stone filled welded gabion baskets

,

4mm wire welded gabion baskets

,

erosion resistant welded gabion

Galvanized Welded Rock Gabion Basket Garden Fence Gabion For Retaining Wall



Description:



Welded Gabion basket is assembled by welded mesh panels, some mesh panels are connected by crossing spirals or C rings. Its beauty appearance and easily installation successfully catch people's eyes.


Welded gabion baskets are widely used for park landscape modeling, building exterior walls, and outsourcing of commercial buildings. The welded gabion has simple construction, beautiful structure, low cost and easy installation features. It is an ideal choice for garden decoration, slope protection, and greening.


At the same time, it is also the premise material for making hesco barrier, which is widely used in the military field and protection.



Specification:



Material:

Galvanized Steel Wire, Galfan Steel Wire/Zinc-5%Aluminum Wire

Wire Diameter:

3 mm, 4mm, 5mm, 6 mm, etc

Aperture:

50*50 mm, 50*100 mm etc

Gabion Box Size:

100*30*30 cm, 100*50*30 cm, 100*100*50 cm, 100*100*100 cm etc.

Finish:

Hot Dipped Galvanized;Heavy Zinc Coating;Galfan Coating;PVC Coated

Normal Box Size(cm)

Diaphragms

Capacity (m3)

Mesh Size(mm)

100x30x30

None

0.09



50×50 or 100×50

 100x50x30

None

0.15

100x100x50

None

0.5

100x100x100

None

1

150x100x50

1

0.75

150x100x100

1

1.5

200x100x50

1

1

200x100x100

1

2

Other sizes can be customized.



Feature:



1. Easy to vegetate and integrate into the use environment.
2. Low cost alternative to concrete or masonry.
3. High tensile strength resistance, easy to resist natural forces.
4. Withstand unknown natural external movements and mitigate damage.
5. Simple and rapid installation, with low cost efficiency.
6. High quality surface treatment and aesthetic appearance.
7. Special gabion mesh size and mesh structure can be produced according to customer needs.



Install:

1. Ends, diaphragms, front and back panels are placed upright on the bottom section of wire mesh.
2. Secure panels by screwing spiral binders through the mesh openings in adjacent panels.
3. Stiffeners shall be placed across the corners, at 300mm from the corner. Providing a diagonal bracing, and crimped over the line and cross wires on the front and side faces. None are needed in interior cells.
4. Gabion box filled with graded stone by hand or with a shovel.
5. After filling, close the lid and secure with spiral binders at the diaphragms, ends, front and back.
6. When stacking tiers of the welded gabion box, the lid of the lower tier may serve as the base of the upper tier. Secure with spiral binders and add pre-formed stiffeners to exterior cells before filling with graded stones.

Application:



-Architectural and Landscaping.
-Retaining wall, perimeter wall/fence.
-Embankment stabilization.
-Store Protection, rivers, reed beds and channel linings prevention of movement or migration of stones.
-Rapid deployment flood protection barriers.



4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets 04mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets 1

4mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets 24mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets 34mm 5mm 6mm Wire Stone Filled Welded Gabion Baskets 4
