Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages

China Anping County PeiGuan Metal Wire Mesh Products Co.,Ltd certification
Fantastic company. So helpful and friendly. Nothing is too much trouble even though I had many questions. Received the fence much faster than I expected. Very good quality. My customers are very pleased with the fence. This easily the best company from China I have done business. I can't recommend them enough.

—— Maja Bjornsdotter

Fast, compenent, good wire mesh fence product quality and great service. We will definitely be a returning customer.

—— Harald Schreiner

I'm Online Chat Now

Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages

Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages
Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages

Large Image :  Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages

Product Details:
Place of Origin: PeiGuan Metal Wire Mesh; Anping; China
Brand Name: PeiGuan
Certification: SGS
Model Number: WMG-J07
Payment & Shipping Terms:
Minimum Order Quantity: 50 Sets
Price: Negotiable
Packaging Details: pallet or in bulk
Delivery Time: According to the order
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10000 Square Meter/Square Meters per Day
Detailed Product Description
Name: Welded Mesh Gabion Material: Low Carbon Iron Wire
Wire Gauge: 5.0 Mm Hole Shape: Square
Aperture: 50*100 Mm Gabion Box Size: 100*30*30 Cm, 100*50*30 Cm, 100*100*50 Cm
Surface Treatment: Zinc Coated Sample: Free But Pay Freight Cost
Application: Gabion Mesh Packing: Pallet
High Light:

4.5mm Welded Mesh Gabion

,

Solid Welded Mesh Gabion

,

Retaining Wall Gabion Cages

4.5mm Galvanised Gabion Rock Wall Cages Gabion Baskets Retaining Wall



Description:



Welded mesh gabions are made from welded low carbon steel wire that meets tensile strength standards and is treated by hot dipped galvanisation or aluminised zinc to ensure a longer life against corrosion and other weather effects, especially when gabions are used in saline and highly polluted environments. Faster and cheaper to install compared to woven mesh gabions, more rigid than woven mesh, resulting in a more uniform finish when constructed and no pre-stretching required.



Specification:



* Material:Galvanized Steel Wire, Galfan Steel Wire/Zinc-5%Aluminum Wire.

* Wire Diameter :3 mm-6 mm.

* Aperture:50*50 mm, 50*100 mm etc.

* Gabion Box Size:100*30*30 cm, 100*50*30 cm, 100*100*50 cm, 100*100*100 cm etc.

* Finish:Hot Dipped Galvanized ; Heavy Zinc Coating ; Galfan Coating; PVC Coated.



Normal Box Size(cm) Diaphragms Capacity (m3) Mesh Size(mm)
100x30x30 None 0.09 50×50 or 100×50
100x50x30 None 0.15
100x100x50 None 0.5
100x100x100 None 1
150x100x50 1 0.75
150x100x100 1 1.5
200x100x50 1 1
200x100x100 1 2
Other sizes can be customized.

Packing:Normally packaged in bundles with pallets.



Feature:



1. Easy to vegetate and integrate into the use environment.
2. Low cost alternative to concrete or masonry.
3. High tensile strength resistance, easy to resist natural forces.
4. Withstand unknown natural external movements and mitigate damage.
5. Simple and rapid installation, with low cost efficiency.
6. High quality surface treatment and aesthetic appearance.
7. Special gabion mesh size and mesh structure can be produced according to customer needs.



Applications:



1. Flood prevention and control.

2. Prevention of rock fragmentation and rock fall.

3. Protection of soil structure.

7. Protection works for seaside harbors.

8. For dust protection wall.

9. Protection of roads and bridges.



Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages 0Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages 1

Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages 2Zinc Coated Welded Mesh Gabion , 4.5mm Retaining Wall Gabion Cages 3



FAQ:



Q: What makes your products different from other companies?
A: Peiguan products provide free design service, customization and warranty service, with strictly quality control and very
competitive price.

Q: Will our fence rush, peel, fade or chip?
A: It shows more details in our warranty policy, if without man-made crash, acid wash etc. The surface can last for more than 10 years.

Q: What type of payment do you accept?
A: We accept Western Union, PayPal, Escrow, L/C, T/T.

Q: Which port do you export mostly?
A: Because our factories located in Anping Country, Hebei Province and the nearest port is Xingang Port (Tianjin), we usually export from Xingang Port.

Q: Do you test your goods before delivery?
A: Yes, we have own specialized equipments and professional inspectors, all the products will be tested before loading.
