Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets

Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets
Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets

Large Image :  Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets

Product Details:
Place of Origin: PeiGuan Metal Wire Mesh; Anping; China
Brand Name: PeiGuan
Certification: SGS
Model Number: WMG-J03
Payment & Shipping Terms:
Minimum Order Quantity: 100 Sets
Price: Negotiable
Packaging Details: pallet or in bulk
Delivery Time: According to the order
Payment Terms: T/T, L/C, Western Union
Supply Ability: 10000 Square Meter/Square Meters per Day
Detailed Product Description
Name: Welded Mesh Gabion Material: Low Carbon Iron Wire
Wire Gauge: 3.0 Mm-5.0 Mm Hole Shape: Square, Rectangle
Aperture: 50*50 Mm, 50*100 Mm Etc Gabion Box Size: 100*30*30 Cm, 100*100*50 Cm
Surface Treatment: Hot Dipped Galvanized Sample: Free But Pay Freight Cost
Certification: SGS Packing: Waterproof Paper
High Light:

Garden Gabion Wall Baskets

,

Rectangle Gabion Wall Baskets

,

Rock Galvanized Gabion Baskets

Galvanized Welded Rock Gabion Basket Garden Fence Gabion For Retaining Wall



Description:



Welded Gabions Stone Cage is made from electric welded wire mesh panels connected by spirals/helicals assembled with spacers/stiffeners, with faster erection time and baskets that last longer and keep their shape for Retaining Structures.
Welded gabion is made of high quality low carbon steel wire, accordance standard through automation, precision and accurate processing machinery and equipment welding row after forming, then it use electro-galvanized, hot dip galvanized, coated, dip or Galfan and other processes where the surface passivization, plastics processing.



Specification:



Material:

Galvanized Steel Wire, Galfan Steel Wire/Zinc-5%Aluminum Wire

Wire Diameter:

3 mm-6 mm

Aperture:

50*50 mm, 50*100 mm etc

Gabion Box Size:

100*30*30 cm, 100*50*30 cm, 100*100*50 cm, 100*100*100 cm etc.

Finish:

Hot Dipped Galvanized;Heavy Zinc Coating;Galfan Coating;PVC Coated

Normal Box Size(cm)

Diaphragms

Capacity (m3)

Mesh Size(mm)

100x30x30

None

0.09



50×50 or 100×50

 100x50x30

None

0.15

100x100x50

None

0.5

100x100x100

None

1

150x100x50

1

0.75

150x100x100

1

1.5

200x100x50

1

1

200x100x100

1

2

Other sizes can be customized.



Feature:



1. Easy to vegetate and integrate into the use environment.
2. Low cost alternative to concrete or masonry.
3. High tensile strength resistance, easy to resist natural forces.
4. Withstand unknown natural external movements and mitigate damage.
5. Simple and rapid installation, with low cost efficiency.
6. High quality surface treatment and aesthetic appearance.
7. Special gabion mesh size and mesh structure can be produced according to customer needs.



Application:



1. Control and guide of water or flood
2. Preventing of rock breaking
3. Rock fall protection
4. Water and soil protection
5. Bridge protection
6. Strengthening structure of soil
7. Protection engineering of seaside area
8. Port project
9. Keep off dust wall
10. Roadway protection



Install:

1. Ends, diaphragms, front and back panels are placed upright on the bottom section of wire mesh.
2. Secure panels by screwing spiral binders through the mesh openings in adjacent panels.
3. Stiffeners shall be placed across the corners, at 300mm from the corner. Providing a diagonal bracing, and crimped over the line and cross wires on the front and side faces. None are needed in interior cells.
4. Gabion box filled with graded stone by hand or with a shovel.
5. After filling, close the lid and secure with spiral binders at the diaphragms, ends, front and back.
6. When stacking tiers of the welded gabion box, the lid of the lower tier may serve as the base of the upper tier. Secure with spiral binders and add pre-formed stiffeners to exterior cells before filling with graded stones.

Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets 0Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets 1

Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets 2Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets 3Garden Gabion Wall Baskets , Rock Galvanized Gabion Baskets 4
