Product Details:
Payment & Shipping Terms:
|
| Product Name: | V Mesh Security Fencing | Wire Diameter: | 3.0mm-6.0mm |
|---|---|---|---|
| Mesh Size: | 50mm*200mm | Height: | 1030mm/1230mm/1530mm/1830mm |
| Length: | 2000mm/2200mm/2500mm/3000mm | Color: | Green,Black,White,Grey,etc |
| Surface Treatment: | Hot Dipped Galvanized/Powder Coated | Feature: | Easily Assembled;Eco Friendly |
| Materials: | Galvanized Steel Wire | Season: | All-Season |
| High Light: | sgs v mesh fencing,3.0mm V Mesh Security Fencing,powder coated v mesh security fencing |
||
Factory Supply Cheap Price Decorative Pvc Powder Coated Welded Wire Mesh V Mesh Security Fence
Product description
V Mesh Security Fencing is also callled as 3D panel fence or curved mesh fence,Which is one of the important way to keep your home safe as well as secured from all forms of attacks by armed robbers and so on.It is very affordable and inexpensive that is why we see most homes using wire fencing for their walls and also very durable and easy to make and fix on fences.
V Mesh Security Fencing is a type of welded wire mesh. It is made of high quality low carbon steel wire, galvanized wire or stainless steel wire connected to metal posts. 3D fence panel has V-shaped bending curves, which look modern and attractive. The sturdy and sleek fence panel is mainly used for security protection in construction site, residential building, sports field, warehouse, highway or airport service area, railway station, etc.
V Mesh Security Fencing has easy structure. It is mainly constructed by wire mesh and metal posts. Robust and sturdy panels will not sag or deform. Resistant to corrosion, rust with galvanized, PVC and powder coated surface treatment. Available in many colors such as green, black, blue, red, white, etc.
Panel Specifications
| Mesh Size | Wire Diameter | Panel Height | Panel Length | Bending No. | Common Color | Surface Treatment |
| 50*200mm 50*100mm 55*200mm 55*100mm |
4mm 5mm |
830mm | 2m 2.2m 2.4m 2.5m 2.8m 3m |
2 |
GreenRAL6005 Grey RAL 7016 |
1.Hot dipped galvanized after black wire welded 3.PE coated after galvanized wire welded 4.Powder coated after galvanized wire welded
|
| 1030mm | 2 | |||||
| 1230mm | 2 | |||||
| 1530mm | 3 | |||||
| 1830mm | 4 | |||||
| 2030mm | 4 | |||||
| 2230mm | 4 | |||||
| 2430mm | 4 |
Square Post&Rectangular Post
| Post Type | Post Size | Post Thickness | Panel Height | Post Height | Surface Treatment |
|
Square Post |
40*40mm |
1.0mm 1.1mm 1.2mm 1.5mm 1.8mm 2.0mm 2.5mm |
830mm | 1200mm |
1.Black tube hot-dipped galvanized 2.Galvanized tube PVC coated 3.Galvanized tube powder coated |
| 1030mm | 1400mm | ||||
| 1230mm | 1600mm | ||||
| 1530mm | 2000mm | ||||
|
Rectangle Post |
30*50mm |
1830mm | 2400mm | ||
| 2030mm | 2600mm | ||||
| 2230mm | 2800mm | ||||
| 2430mm | 3000mm |
Peach Post
| Post Type | Post Size | Thickness | Panel Height | Post Height | Surface Treatment |
|
Peach Post |
50*70mm |
1.0mm 1.1mm 1.2mm
|
830mm | 1200mm |
Galvanized tube powder coated |
| 1030mm | 1400mm | ||||
| 1230mm | 1600mm | ||||
| 1530mm | 2000mm | ||||
|
70*100mm |
1830mm | 2400mm | |||
| 2030mm | 2600mm | ||||
| 2230mm | 2800mm | ||||
| 2430mm | 3000mm |
Process
1. Booking the material wire and pipe material
2. material wire zinc coating test
3. welding wire mesh and cut pipe as size
4. Paint or galvanized for the panel and pipe
5. package and loading
Usage
1. High security projects
2. Borders
3. Transportation projects
4. Industrial facilities
5. Sports facilities
6. Residential projects
