Product Details:
Payment & Shipping Terms:
|
| Product Name: | V Mesh Security Fencing | Length: | 2000mm/2200mm/2500mm/3000mm |
|---|---|---|---|
| Height: | 1030mm/1230mm/1530mm/1830mm | Mesh Size: | 50*200mm |
| Post Type: | Peach Post/Square Post | Size: | Customized Size |
| Metal Type: | Steel | Color: | Green, Blue, Red, Etc. |
| Feature: | Easily Assembled, ECO FRIENDLY, Rodent Proof, Rot Proof | Usage: | Garden Fence, Highway Fence, Sport Fence, Farm Fence |
| High Light: | 2000mm V Mesh Security Fencing,SGS V Mesh Security Fencing,Eco Friendly 2000mm Welded Wire Mesh Fence |
||
50*200mm Mesh Hot Dipped Galvanized Metal V Mesh Security Fencing For Farm Fence
Product Information
V Mesh Security Fencing is also called welded wire mesh fence, welded fence, 3D panel fence or curved mesh fence, it has a simple structure and beautiful appearance. This kind of fence is light but durable, it is composed of simply welded wires together to make the fence. v-curve will make the welded mesh panels more stable and stable.It is widely used in lots of places,such as living quarters,markets of gardens,park and industrial park.companies ,protection for road, highway and so on.
V Mesh Security Fencing is one of the most important ways to keep your home safe from all forms of attacks such as armed robbers. And it is very economical, inexpensive and also very durable, which is why we see most homes using wire fencing, which is easy to make and secure to the fence.
Panel Specifications
| Mesh Size | Wire Diameter | Panel Height | Panel Length | Bending No. | Common Color |
|
50*200mm |
4mm |
830mm | 2m 2.2m 2.4m 2.5m 2.8m 3m |
2 |
GreenRAL6005 Grey RAL 7016 |
| 1030mm | 2 | ||||
| 1230mm | 2 | ||||
| 1530mm | 3 | ||||
| 1830mm | 4 | ||||
| 2030mm | 4 | ||||
| 2230mm | 4 | ||||
| 2430mm | 4 |
Square Post&Rectangular Post
| Post Type | Post Size | Post Thickness | Panel Height | Post Height |
|
Square Post |
40*40mm |
1.0mm 1.1mm 1.2mm 1.5mm 1.8mm 2.0mm 2.5mm |
830mm | 1200mm |
| 1030mm | 1400mm | |||
| 1230mm | 1600mm | |||
| 1530mm | 2000mm | |||
|
Rectangle Post |
30*50mm |
1830mm | 2400mm | |
| 2030mm | 2600mm | |||
| 2230mm | 2800mm | |||
| 2430mm | 3000mm |
Peach Post
| Post Type | Post Size | Thickness | Panel Height | Post Height |
|
Peach Post |
50*70mm |
1.0mm 1.1mm 1.2mm
|
830mm | 1200mm |
| 1030mm | 1400mm | |||
| 1230mm | 1600mm | |||
| 1530mm | 2000mm | |||
|
70*100mm |
1830mm | 2400mm | ||
| 2030mm | 2600mm | |||
| 2230mm | 2800mm | |||
| 2430mm | 3000mm |
Process
1. Reservation of electric wire and pipe material of material
2. Galvanized layer test of material wire
3. Welding wire netting and measuring and cutting pipes to size
4. Painting or galvanizing of plates and pipes
5. Packing and loading
Applications
1. Security for residential areas and schools
2. Safety for construction sites and private property
3. Used for traffic control and crowd control
4. Used for large public events, sports, music concerts, festivals and gatherings
5. Can be buried underground to prevent animals from burrowing in
6. Used as a barrier fence or security fence for roads and railroads
Surface Treatment
1. Galvanized tube powder coated
2. Hot dipped galvanized after black wire welded
3. PVC coated after galvanized wire welded
4. PE coated after galvanized wire welded
5. Powder coated after galvanized wire welded
6. Black tube hot-dipped galvanized
7. Galvanized tube PVC coated
Service
We have a variety of sizes and finishes in stock but if you want something a little different we also do custom orders. Contact us with what you need and we'll build the perfect fence for you.
