| Product Name: | V Mesh Security Fencing | Mesh Size: | 50*200mm |
|---|---|---|---|
| Common Wire Diameter: | 3.0mm-6.0mm | Length: | 2000mm/2200mm/2500mm/3000mm |
| Height: | 1030mm/1230mm/1530mm/1830mm | Surface Treatment: | Hot Dipped Galvanized/Powder Coated |
| Color: | Green, Blue, Black, White | Service: | 3D Modeling, 3D Sample Models, Video Of Installation |
| Frame Material: | Metal | Frame Finishing: | Powder Coated |
| High Light: | 2m V Mesh Security Fencing,Black V Mesh Security Fencing,Galvanized Wire 3D Panel Fence |
||
2m Height Galvanized Wire Black V Mesh Security Fencing With Peach Post
Product description
V mesh security fencing also called 3D curved fence panels,triangle bending fence.it is widely used in lots of places,such as living quarters,markets of gardens,park and industrial park.companies ,protection for road, highway and so on.V mesh security fencing is made of premium steel wire line welded, then plating , hot dipped plating, PVC coated surface dulling, plasticizing treatment, with a smooth surface, uniform mesh holes, firmly welded junctions, excellent local machining capabilities, high stability and corrosion resistance.V-mesh security fence is a kind of welded wire mesh. It is made of good grade low carbon steel wire, galvanized wire or stainless steel wire joined with metal posts. 3D fence panels have V-shaped curved curve, which looks contemporary and appealing.
Panel Specifications
| Mesh Size | Wire Diameter | Panel Height | Panel Length | Bending No. | Common Color |
| 50*200mm 50*100mm 55*200mm 55*100mm |
4mm 5mm |
830mm | 2m 2.2m 2.4m 2.5m 2.8m 3m |
2 |
GreenRAL6005 Grey RAL 7016 |
| 1030mm | 2 | ||||
| 1230mm | 2 | ||||
| 1530mm | 3 | ||||
| 1830mm | 4 | ||||
| 2030mm | 4 | ||||
| 2230mm | 4 | ||||
| 2430mm | 4 |
Square Post&Rectangular Post&Peach Post
| Post Type | Post Size | Post Thickness | Panel Height | Post Height |
|
Square Post |
40*40mm |
1.0mm 1.1mm 1.2mm 1.5mm 1.8mm 2.0mm 2.5mm |
830mm | 1200mm |
| 1030mm | 1400mm | |||
| 1230mm | 1600mm | |||
| 1530mm | 2000mm | |||
|
Rectangle Post |
30*50mm |
1830mm | 2400mm | |
| 2030mm | 2600mm | |||
| 2230mm | 2800mm | |||
| 2430mm | 3000mm | |||
|
Peach Post |
50*70mm 70*100mm |
1.0mm |
830mm | 1200mm |
|
1.1mm |
||||
| 1.2mm | 1030mm | |||
| 1230mm | ||||
| 1530mm | ||||
| 1830mm | 1400mm | |||
| 2030mm | ||||
| 2230mm | 1600mm | |||
| 2430mm | 2000mm | |||
| 2400mm | ||||
| 2600mm | ||||
| 2800mm | ||||
| 3000mm |
Surface Treatment
1. Hot dipped galvanized after black wire welded
2. PVC coated after galvanized wire welded
3. PE coated after galvanized wire welded
4. Powder coated after galvanized wire welded
5. Black tube hot-dipped galvanized
6. Galvanized tube PVC coated
7. Galvanized tube powder coated
Applications
1. High security projects
2. Borders
3. Transportation projects
4. Industrial facilities
5. Sports facilities
6. Residential projects
7. Warehouse protection fence
8. Agriculture security fence
9. Animal enclosure fence
Features
1. Large open mesh holes provide high visibility
2. The athletic field is enclosed by a white painted 3D wire fence
3. Strong and durable panels that won't dip or distort
4. Anticorrosive layer can life of the products
5. Smooth surface with no sharp edges.
6. We will provide instruction manual which is easy to understand and easy to assemble
effectively isolates external pollution, greatly prolongs the service
Packing
1. Fence panel: plastic film + wood / metal pallet.
2. Fence post: every post pack with a plastic bag (the cap is covered well on the post)+metal pallet.
3. Accessory: small plastic bag + carton box.
