Product Details:
Payment & Shipping Terms:
|
Product Name: | Double Wire Fence | Material: | Steel Metal |
---|---|---|---|
Wire Diameter: | 3.00mm-5.00mm | Mesh Size: | 50x200mm,50×100mm |
Length: | 10m, 30m, 50m | Height: | 1.03 M-2.43m |
Surface Treatment: | Galvanized,PVC Coated | Colors: | Customized |
Post Type: | Square Post | Feature: | Easily Assembled, ECO FRIENDLY |
Service: | 3D Modeling, Video Of Installation | ||
High Light: | 868 mesh powder coated fence,powder coated 868 mesh fence,double twist powder coated fence |
868 Powder Coated Double Twist Galvanized Wire Iron Wire Double Wire Fence
Description:
Double wire mesh fence, also called 2D fence panel, It is a special design fence, which have a double horizontal wire. It has refining deign, plain panel and installs convenient.Double wire welded mesh fence is welded with one vertical wire and two horizontal wires; according to wire thickness, the fence can be divided into 6/5/6 type and 8/6/8 type. This can be strong enough, compared to the normal welded fence panel.Our double wire fence is made of Q195 or Q235 low carbon steel wire material, and the surface treatment is galvanized, powder coated or PVC coated, according to customer's request.
Specification:
Wire Diameter
|
Mesh Size
|
Panel Height(mm)
|
Panel Width(mm)
|
Post Height(mm)
|
Post Size
|
8/6/8mm
6/5/6mm
5/4/5mm |
200*50mm
|
630
|
2500
|
1100
|
60*60*2mm
80*80*2mm
|
830
|
2500
|
1300
|
|||
1030
|
2500
|
1500
|
|||
1230
|
2500
|
1700
|
|||
1430
|
2500
|
1900
|
|||
1630
|
2500
|
2100
|
|||
1830
|
2500/3000
|
2400
|
|||
2030
|
2500/3000
|
2600
|
|||
2230
|
2500/3000
|
2800
|
|||
2430
|
2500/3000
|
3000
|
|||
Material
|
Low carbon steel wire,Galvanized wire,etc.
|
||||
Surface treatment
|
Hot dip galvanized,Powder coated,etc.
|
Detail:
Application:
Packing terms:
Contact Person: Mrs. Xia
