Beijing Silk Road Enterprise Management Services Co.,LTD
Home ProductsDouble Wire Fence

Low Carbon Steel Double Wire Welded Fence

Fantastic company. So helpful and friendly. Nothing is too much trouble even though I had many questions. Received the fence much faster than I expected. Very good quality. My customers are very pleased with the fence. This easily the best company from China I have done business. I can't recommend them enough.

—— Maja Bjornsdotter

Fast, compenent, good wire mesh fence product quality and great service. We will definitely be a returning customer.

—— Harald Schreiner

I'm Online Chat Now

Low Carbon Steel Double Wire Welded Fence

Low Carbon Steel Double Wire Welded Fence
Low Carbon Steel Double Wire Welded Fence Low Carbon Steel Double Wire Welded Fence Low Carbon Steel Double Wire Welded Fence Low Carbon Steel Double Wire Welded Fence

Large Image :  Low Carbon Steel Double Wire Welded Fence

Product Details:
Place of Origin: China
Certification: SGS
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: pallet or in bulk
Delivery Time: According to the order
Payment Terms: L/C, D/A, D/P, Western Union, T/T, MoneyGram
Supply Ability: 5000 Sets per Month
Detailed Product Description
Product Name: Double Wire Fence Wire Diameter: 3.0-6.0 Mm
Clamp: Metal Clamp / Anti-UV PP Plastic Clamp Panel Height: 900mm, 1200mm, 1500mm, 1800mm, 2100mm, 2400mm
Panel Width: 1000mm, 1500mm, 2000mm, 2400mm, 2500mm, 3000mm Mesh Size: 50*100mm, 50*150mm, 50*200mm, Etc.
Color: Available Any RAL Surface Treatment: PVC Coated,powder Coated Or Galvanized
Place Of Origin: Hebei, China Material: Low Carbon Steel Wire
High Light:

Farm Double Wire Welded Fence

,

High Strength Double Wire Welded Fence

,

50×200mm 656 Mesh Fencing

50*200mm Powder Coated Low Carbon Steel Wire Double Wire Fence For Farm Fence





Product Information



Double wire fence,also known as double-layer wire fence. It is a kind of welded fence in Skyhall fence series. The special feature of double wire fence is its horizontal line. Typically, it is designed with two horizontal lines and one horizontal hole. For the normal type it is 6mm/5mm/6mm wire thickness, while for the stronger type we use 8mm/6mm/8mm wire thickness for the double wire fence. The thickness of wire in the middle above refers to vertical wire. The mesh size of double wire fence is the same as the welded wire mesh, which is the common type -50mm*200mm. Normally, double wire fence can't have pleats because its vertical wire is too strong to bend. However, 30mm spikes can be set at the top during the production process to prevent people from overturning.



Double wire fence is widely used in cities, especially in the German market. Most of the customers who buy the double wire fence are using it in the German market and in huge quantity. We are equipped with automatic wire adding machine in the production process, the production capacity is greatly improved and the cost is reduced, which can fully meet the market demand and is very competitive compared with other kinds of fences.



Specifications



Double Wire Fence
Wire Diameter Mesh Size Panel Height (mm) Panel Width (mm) Post Height (mm) Post Size (mm)

8/6/8 mm

6/5/6 mm

5/4/5 mm

200*50 mm 630 2500 1100

60*60*2

80*80*2

830 2500 1300
1030 2500 1500
1230 2500 1700
1430 2500 1900
1630 2500 2100
1830 2500/3000 2400
2030 2500/3000 2600
2230 2500/3000 2800
2430 2500/3000 3000



Features


1. Multiple options for installation
Due to the appearance of the double wire fence panel except the extra horizontal line, it seems very normal, whether it is the V-clip of BRC fence, the metal clip/plastic clip of welded mesh fence, or the dovetail post of European style fence, the double wire fence can be installed with different accessories. So the fence panel can be applied to many various posts and connection styles.
2. Thick wire diameter
The double wire guardrail's wire diameter is also make it unique another feature. The maximum line diameter of horizontal line can reach 8.0mm, and the additional line diameter is also 8.0mm thick. Even the vertical line can reach a thickness of 6.0 mm. This makes the double line more robust than other types of fences.
3. Double-layer horizontal wire
Double-layer wire fence is named because of its double horizontal line feature. In purpose of making the fence panel stronger, the designer adds another extra horizontal line on the fence panel. Double wire fence is the only kind of fence that has double horizontal lines in the panels. Double line is a particular design for double line guardrail only.



Advantages



1. Easy installation


To begin with, dig a hole to bury the column into the ground and fix it with the foot bolt. Then the double line guardrail plate will stand up, but pay attention to its weight, so that the guardrail plate near the column. If the ground is concrete, you can use the flange to pick the column. Finally, use the clip to fix the double line guardrail plate and column together can be.



2. Convenient transportation


The transportation of double wire fence is very convenient too. Double wire fence consists of fence panels, posts and clips, rain caps and other accessories. It can be packed by these three parts.



3. High strength


Double wire fence is made of two horizontal lines and one vertical line welded together. Therefore the rigidity and durability of double pole fence is beyond doubt. It has one more horizontal wire than ordinary wire fence, so it has more strength. The common thickness of wire for double-layer wire fence is 8mm/6mm/8mm or 6mm/5mm/6mm. These wire thicknesses are quite large for wire fencing products.



Packing terms



1. 50-80sets/pallet,wraped with plastic film interside,packed in pallet
2. Or as customer requirement



Our Service



1. Provide most of free samples

2. Spot inspection and finished product inspection

3. 24 hours to answer your questions and doubts





Low Carbon Steel Double Wire Welded Fence 0

Low Carbon Steel Double Wire Welded Fence 1

Low Carbon Steel Double Wire Welded Fence 2
