| Product Name: | V Mesh Security Fencing | Material: | Steel |
|---|---|---|---|
| Wire Diameter: | 3-6mm | Hole Size: | 50*200mm |
| Length: | 2000mm/2200mm/2500mm/3000mm | Height: | 1030mm/1230mm/1530mm/1830mm |
| Folded No: | 2/3/4 | Post Type: | Peach Post/ Square Post |
| Surface Treatment: | Hot Dipped Galvanized/ Powder Coated | Room Space: | Outdoor |
| High Light: | Airport 3mm V Mesh Security Fencing,20m V Mesh Security Fencing,Airport V Mesh Fence Panels |
||
3mm Wire diameter Galvanized Bending V Mesh Security Fencing In Airport
Description:
V mesh security fencing is also named as 3D Panel Fence or curved mesh fence,The 3D Panel Fences are installed around residential houses, parks, gardens, public utility buildings, and playgrounds, as well as around factories and various sorts of storage or warehouse areas.It has simple structure and nice appearance,the V curves will make the welded mesh panel more stable and stronger. The panels feature 'V' shaped beams at the top, centre and bottom edges, which not only enhance the appearance but also provide an integral support spanning between the posts.
Panel Specification:
| Mesh Size |
Wire Diameter |
Panel Height |
Panel Length |
Bending No. | Common Color | Surface Treatment |
|
50*200mm 50*100mm 55*200mm 55*100mm |
4mm 5mm |
830mm |
2m 2.2m 2.4m 2.5m 2.8m 3m |
2 |
Green RAL 6005 Grey RAL 7016 Brown RAL 8019 Black RAL 9005 White RAL 9010 |
1.Hot dipped galvanized after black wire welded
2.PVC coated after galvanized wire welded
3.PE coated after galvanized wire welded
4.Powder coated after galvanized wire welded |
| 1030mm | 2 | |||||
| 1230mm | 2 | |||||
| 1530mm | 3 | |||||
| 1830mm | 4 | |||||
| 2030mm | 4 | |||||
| 2230mm | 4 | |||||
| 2430mm | 4 |
Square Post & Rectangular Post:
|
Post Type |
Post Size |
Thickness |
Panel Height |
Post Height |
Surface Treatment |
| Square Post |
40*40mm 50*50mm 60*60mm |
1.0mm 1.1mm 1.2mm 1.5mm 1.8mm 2.0mm 2.5mm |
830mm | 1200mm |
1.hot-dipped galvanize 2.PVC coated 3.powder coated |
| 1030mm | 1400mm | ||||
| 1230mm | 1600mm | ||||
| 1530mm | 2000mm | ||||
| Rectangle Post |
30*50mm 40*60mm 60*80mm |
1830mm | 2400mm | ||
| 2030mm | 2600mm | ||||
| 2230mm | 2800mm | ||||
| 2430mm | 3000mm |
Peach Post:
| Post Type | Post Size | Thickness | Panel Height | Post Height | Surface Treatment |
| Peach Post | 50*70mm |
1.0mm 1.1mm 1.2mm |
830mm | 1200mm | Galvanized tube powder coated |
| 1030mm | 1400mm | ||||
| 1230mm | 1600mm | ||||
| 1530mm | 2000mm | ||||
| 70*100mm | 1830mm | 2400mm | |||
| 2030mm | 2600mm | ||||
| 2230mm | 2800mm | ||||
| 2430mm | 3000mm |
Process:
1: Mild steel wire → welding → hot dip galvanising → powder coating/PVC coating
2: Mild steel wire → welding → electro-galvanised surface treatment → powder coating/PVC coating
3: Mild steel wire → hot dip galvanised surface treatment → welding → powder coating/PVC coating
4: Mild steel wire → electro-galvanised surface treatment → welding → powder coating/PVC coating
Technology:
The V mesh security fencing is made of low carbon steel wire welded into welded wire mesh, bent by the press bending machine, bending mesh by the customer to decide the number of bending, generally 2-3. The mesh without surface treatment then according to customer needs after hot dip galvanizing treatment, plastic coating or plastic spraying treatment, forming the final V-shaped fence mesh, plastic coating or plastic spraying treatment color according to RAL international color card, the common color to RAL6005 mainly, we can also provide other customer needs of color.
Advantage:
1. high overall strength and distinctive decorative effect.
2. Firmly welded, easy to cut and not easy to break.
3. High-grade dipping treatment, guaranteed not to rust for ten years.
4. Easy to install and dismantle, convenient to reuse and adjust as needed.
5. Environmentally friendly product, recyclable.
Packing terms:
Fence panel: plastic film + wood / metal pallet.
Fence post: every post pack with a plastic bag (the cap is covered well on the post)+metal pallet.
Accessory: small plastic bag + carton box.
